Throw
332mm -
Height
566mm -
Diameter
Ø 22mm -
Material
Aluminium
MA22-090-01-4-T6
The MA22-090-01-4-T6 is an extra-tall, heavy-duty closed-loop mounting assembly engineered for large-scale commercial and tactical vehicle mirror systems requiring maximum vertical span and structural integrity. Precision-crafted from high-strength T6-grade aluminum alloy, it features dual-anchor hinge blocks linked by a reinforced, double-window vertical frame, offering unmatched resistance against severe vibration, mechanical stress, and high-speed wind resistance.
ENQUIRE NOW-
B2B COMMERCIAL / EXPORT
Full System Specifications
Structural & Material Specifications
-
Material Grade
6061-T6 Aircraft-Grade Aluminum Alloy
-
Surface Treatment
Severe-Duty Anodized Matte Black
-
Frame Profile
Extra-Tall Closed-Loop C-Frame with Dual Horizontal Extension Bays
-
Structural Rating
Severe-Duty Tactical Grade
Mounting & Environmental Performance
-
Base Mounting Interface
Dual Heavy-Duty Hinge Block Anchors (Top & Bottom Multi-Bolt Flanges)
-
Load Capacity
Up to 38 kg (83.8 lbs) Static / 22 kg (48.5 lbs) Dynamic
-
Vibration Dampening
Multi-Point Dual-Anchor High-Durometer Isolation Bushings
-
Operating Temperature
-55°C to +125°C
Available Variants
Multiple barrel length and configuration options — from ultra-compact CQB to full-length designated marksman configurations.
-
01B2B COMMERCIAL / EXPORT
MA22-024-01-4-T6
The MA22-024-01-4-T6 is an extended-height, heavy-duty mounting arm assembly engineered for high-reach bracketry and overhead mirror positioning on specialized vehicles. Constructed from high-tensile T6-grade aluminum alloy, it features an elongated vertical riser, a reinforced dual-window horizontal span, and a heavy-duty hinged base built to resist severe operational vibration and mechanical strain.
-
02B2B COMMERCIAL / EXPORT
MA22-062-01-4-T6
The MA22-062-01-4-T6 is an extended dual-bay mounting arm assembly engineered to provide exceptional outboard reach and vertical clearance for commercial and tactical vehicle mirror systems. Precision-fabricated from high-grade T6 aluminum alloy, it features a widened dual-window horizontal extension paired with an extra-tall upright riser to ensure solid structural support, drag resistance, and vibration isolation under high-speed operational conditions.
-
03B2B COMMERCIAL / EXPORT
MA-635
The MA-635 is an S-curve extended vertical mirror mounting arm engineered for medium-duty commercial and fleet vehicles requiring lateral offset along with high overhead clearance. Designed with a continuous tubular boom featuring an offset swan-neck bend attached to a heavy-duty single-pivot hinge base, it ensures optimal field-of-view positioning, aerodynamic stability, and vibration dampening under rugged operational conditions.
-
04B2B COMMERCIAL / EXPORT
MA-610
The MA-610 is an extended drop-down L-arm mirror mounting assembly engineered for medium-duty commercial and fleet vehicles requiring downward mirror positioning and expanded lateral visibility. Designed with a continuous tubular frame featuring a high-rise bend and long vertical drop attached to a heavy-duty single-hinge pivot base, it offers optimal load balance, wind resistance, and vibration dampening in severe operational environments.
-
05B2B COMMERCIAL / EXPORT
VM3 Series
The VM3 Series is a heavy-duty, high-visibility vehicle mirror system engineered to deliver maximum field of view and operational durability in demanding environments. Featuring a compact 207 x 146 mm (8.1" x 5.74") high-clarity lens, it enhances operator situational awareness, reduces blind spots, and withstands harsh vehicular vibration and environmental conditions.
-
06B2B COMMERCIAL / EXPORT
VM5 Series
The VM5 Series is a premium, extended-view vehicle mirror system engineered for maximum blind-spot reduction and operational safety in high-risk environments. Featuring an expanded 196 x 296 mm (7.71" x 11.65") high-clarity lens, it delivers ultra-wide coverage, superior rearward visibility, and robust vibration damping across heavy industrial and military fleet applications.
-
07B2B COMMERCIAL / EXPORT
MA-006
The MA-006 is a compact, medium-duty ball-head mounting arm designed for precision vehicle auxiliary mirror and device mounting. Precision-engineered with a sleek, solid cantilever extension arm attached to a vertical hinge base and topped with a standardized spherical ball stud, it provides multi-axis tilt and rotation adjustment while offering robust vibration resistance under demanding field conditions.
-
08B2B COMMERCIAL / EXPORT
KVA-004
The KVA-004 is a rigid, angled extension mirror mounting arm engineered for medium-duty commercial and utility vehicles requiring fixed outward reach and downward angle positioning. Built with a solid flat baseplate mount connected to a tubular boom featuring a distinct downward bend, it ensures optimal field-of-view extension, high structural rigidity, and effective vibration dampening under rugged operational conditions.
