Throw
332mm -
Height
566mm -
Diameter
Ø 22mm -
Material
Aluminium
MA22-080-01-4-T6
The MA22-080-01-4-T6 is an extended dual-bay closed-loop mounting assembly engineered for heavy-duty vehicular mirror systems requiring maximum stability and extended outward reach. Precision-machined from high-strength T6-grade aluminum alloy, it features dual-anchor hinge mounting blocks connected by a multi-window reinforced frame, providing exceptional torsional rigidity, wind-load resistance, and vibration isolation under severe operational conditions.
ENQUIRE NOW-
B2B COMMERCIAL / EXPORT
Full System Specifications
Structural & Material Specifications
-
Material Grade
6061-T6 Aircraft-Grade Aluminum Alloy
-
Surface Treatment
Textured Matte Black Anodized
-
Frame Profile
Extended Closed-Loop C-Frame with Dual Horizontal Support Bays
-
Structural Rating
Heavy Industrial
Mounting & Environmental Performance
-
Base Mounting Interface
Dual Heavy-Duty Hinge Block Mounts (Top & Bottom Flanges)
-
Load Capacity
Up to 35 kg (77 lbs) Static / 20 kg (44 lbs) Dynamic
-
Vibration Dampening
Multi-Point Dual-Anchor Elastomeric Isolation Bushings
-
Environmental Resistance
Weatherproof, Salt-Spray, and Extreme UV Resistant
Available Variants
Multiple barrel length and configuration options — from ultra-compact CQB to full-length designated marksman configurations.
-
01B2B COMMERCIAL / EXPORT
KVA-005
The KVA-005 is a wide-reach angled extension mirror mounting arm designed for medium-duty commercial and utility vehicles requiring extended lateral clearance and downward viewing angles. Constructed with a broad square mounting plate and a continuous tubular boom featuring a downward elbow bend, it delivers maximum stability, high torsional strength, and effective vibration mitigation under rugged operating conditions.
-
02B2B COMMERCIAL / EXPORT
MA22-051-01-4-T6
The MA22-051-01-4-T6 is an ultra-tall, gusset-reinforced heavy-duty mounting arm designed for severe-duty vehicle applications demanding high structural stability at maximum vertical reach. Crafted from high-strength T6-grade aluminum alloy, it features an integrated diagonal truss strut bridging the dual-bay base frame to an extra-long vertical riser, providing exceptional rigidity against high-speed wind loads and heavy dynamic vibration.
-
03B2B COMMERCIAL / EXPORT
MA22-023-01-4-T6
The MA22-023-01-4-T6 is a heavy-duty, L-shaped mounting arm assembly designed for secure attachment and precise positioning of vehicular mirror systems and auxiliary equipment. Constructed from high-strength T6-grade aluminum alloy, it features a dual-frame reinforced structure and a hinged pivot base for maximum stability, impact resistance, and vibration dampening under severe operational conditions.
-
04B2B COMMERCIAL / EXPORT
MA22-039-01-4-T6
The MA22-039-01-4-T6 is a compact, high-rigidity mirror mounting arm engineered for tight-clearance vehicular applications requiring high stability. Built with a single-bay reinforced loop body and an ultra-tall vertical upright, this high-strength T6 aluminum alloy arm offers maximum structural support and vibration reduction while maintaining a slim lateral profile.
-
05B2B COMMERCIAL / EXPORT
MA22-098-01-4-T6
The MA22-098-01-4-T6 is an extended-outreach mounting arm assembly designed for wide-body vehicles requiring significant side clearance and overhead riser positioning. Precision-crafted from high-strength T6-grade aluminum alloy, it features a widened dual-window horizontal extension paired with an ultra-tall vertical stem, delivering optimal structural load balance, drag stability, and vibration dampening under rugged operational conditions.
-
06B2B COMMERCIAL / EXPORT
KVA-003
The KVA-003 is a curved gooseneck mirror mounting arm engineered for commercial and medium-duty utility vehicles requiring overhead reach and downward angle positioning. Featuring a high-arching curved tubular boom attached to a angled pivot mounting flange, it provides optimal blind-spot coverage, aerodynamic stability, and effective vibration isolation under severe field conditions.
-
07B2B COMMERCIAL / EXPORT
MA22-062-01-4-T6
The MA22-062-01-4-T6 is an extended dual-bay mounting arm assembly engineered to provide exceptional outboard reach and vertical clearance for commercial and tactical vehicle mirror systems. Precision-fabricated from high-grade T6 aluminum alloy, it features a widened dual-window horizontal extension paired with an extra-tall upright riser to ensure solid structural support, drag resistance, and vibration isolation under high-speed operational conditions.
-
08B2B COMMERCIAL / EXPORT
MA22-057-01-4-T6
The MA22-057-01-4-T6 is an extended-vertical mounting arm engineered for specialized vehicle mirror setups requiring high overhead clearance paired with a compact footprint. Precision-machined from high-strength T6-grade aluminum alloy, it features a single-window square base loop coupled with an extra-long vertical riser stem to provide stable positioning and vibration dampening under severe field conditions.
