Throw
361mm -
Height
417mm -
Diameter
Ø 22mm -
Material
Aluminium
MA22-023-01-4-T6
The MA22-023-01-4-T6 is a heavy-duty, L-shaped mounting arm assembly designed for secure attachment and precise positioning of vehicular mirror systems and auxiliary equipment. Constructed from high-strength T6-grade aluminum alloy, it features a dual-frame reinforced structure and a hinged pivot base for maximum stability, impact resistance, and vibration dampening under severe operational conditions.
ENQUIRE NOW-
B2B COMMERCIAL / EXPORT
Full System Specifications
Structural & Material Specifications
-
Material Grade
6061-T6 Aircraft-Grade Aluminum Alloy
-
Surface Treatment
Anodized Matte Black / Anti-Corrosion Powder Coating
-
Frame Profile
Dual-Window Reinforced Horizontal Span with Vertical Riser Stem
-
Structural Rating
Heavy-Duty Industrial Standard
Mounting & Environmental Performance
-
Base Mounting Interface
Heavy-Duty Single-Hinge Pivot Clamp
-
Load Capacity
Up to 18 kg (40 lbs) Static / 10 kg (22 lbs) Dynamic
-
Vibration Dampening
Integrated High-Durometer Bushings
-
Operating Temperature
-55°C to +120°C
Available Variants
Multiple barrel length and configuration options — from ultra-compact CQB to full-length designated marksman configurations.
-
01B2B COMMERCIAL / EXPORT
MA22-079-01-4-T6
The MA22-079-01-4-T6 is a full-frame, dual-anchor closed loop mounting assembly engineered for heavy-duty vehicle mirror systems requiring maximum structural rigidity and stability. Precision-machined from high-strength T6-grade aluminum alloy, it features a C-clamp dual-hinge configuration with top and bottom mounting blocks connected by a multi-bay vertical frame, providing exceptional torsional strength, wind-load resistance, and vibration isolation under severe operational environments.
-
02B2B COMMERCIAL / EXPORT
MA22-098-01-4-T6
The MA22-098-01-4-T6 is an extended-outreach mounting arm assembly designed for wide-body vehicles requiring significant side clearance and overhead riser positioning. Precision-crafted from high-strength T6-grade aluminum alloy, it features a widened dual-window horizontal extension paired with an ultra-tall vertical stem, delivering optimal structural load balance, drag stability, and vibration dampening under rugged operational conditions.
-
03B2B COMMERCIAL / EXPORT
MA-600
The MA-600 is an inverted U-loop mirror mounting arm engineered for medium-duty commercial and fleet vehicles requiring dual-point mirror attachment and wide-view stability. Designed with a continuous curved tubular frame mounted to a vertical single-hinge pivot base, it provides exceptional structural balance, wind resistance, and vibration isolation for main and auxiliary side-view mirrors.
-
04B2B COMMERCIAL / EXPORT
VM4 Series
The VM4 Series is a heavy-duty, high-visibility vehicle mirror system engineered to deliver maximum field of view and operational durability in demanding environments. Featuring a compact 200 x 200 mm (7.8" x 7.8") high-clarity lens, it enhances operator situational awareness, reduces blind spots, and withstands harsh vehicular vibration and environmental conditions.
-
05B2B COMMERCIAL / EXPORT
MA-640
The MA-640 is an extended S-curve vertical mirror mounting arm engineered for medium-duty commercial and fleet vehicles requiring a right-hand offset along with high overhead clearance. Precision-fabricated with a 16 mm tubular profile featuring a swan-neck S-bend attached to a heavy-duty single-pivot hinge base, it ensures optimal field-of-view positioning, low wind resistance, and superior vibration dampening under rugged operational conditions.
-
06B2B COMMERCIAL / EXPORT
VM3 Series
The VM3 Series is a heavy-duty, high-visibility vehicle mirror system engineered to deliver maximum field of view and operational durability in demanding environments. Featuring a compact 207 x 146 mm (8.1" x 5.74") high-clarity lens, it enhances operator situational awareness, reduces blind spots, and withstands harsh vehicular vibration and environmental conditions.
-
07B2B COMMERCIAL / EXPORT
MA22-062-01-4-T6
The MA22-062-01-4-T6 is an extended dual-bay mounting arm assembly engineered to provide exceptional outboard reach and vertical clearance for commercial and tactical vehicle mirror systems. Precision-fabricated from high-grade T6 aluminum alloy, it features a widened dual-window horizontal extension paired with an extra-tall upright riser to ensure solid structural support, drag resistance, and vibration isolation under high-speed operational conditions.
-
08B2B COMMERCIAL / EXPORT
MA-615
The MA-615 is an extended horizontal-outreach mirror mounting arm engineered for medium-duty commercial and utility vehicles requiring wide lateral extension and optimal field of view. Designed with a continuous tubular boom featuring a sweeping 90-degree bend mounted to a heavy-duty single-pivot hinge base, it delivers superior structural stability, low wind drag, and exceptional vibration dampening under severe field conditions.
