Throw
138mm -
Height
131.2mm -
Diameter
Ø 24mm -
Material
Mild Steel
MA-006
The MA-006 is a compact, medium-duty ball-head mounting arm designed for precision vehicle auxiliary mirror and device mounting. Precision-engineered with a sleek, solid cantilever extension arm attached to a vertical hinge base and topped with a standardized spherical ball stud, it provides multi-axis tilt and rotation adjustment while offering robust vibration resistance under demanding field conditions.
ENQUIRE NOW-
B2B COMMERCIAL / EXPORT
Full System Specifications
Structural & Material Specifications
-
Material Grade
High-Strength Die-Cast Aluminum Alloy
-
Surface Treatment
Smooth Matte Black Finish
-
Frame Profile
Solid Cantilever Arm with Integrated Spherical Ball Mount
-
Structural Rating
Medium-Duty Commercial Standard
Mounting & Environmental Performance
-
Base Mounting Interface
Vertical Single-Pivot Hinge Block Mount
-
Load Capacity
Up to 12.5 kg (27.5 lbs) Static / 7.5 kg (16.5 lbs) Dynamic
-
Vibration Dampening
Integrated High-Durometer Synthetic Bushings
-
Environmental Resistance
Weatherproof, UV-Resistant, and Salt-Spray Protected
Available Variants
Multiple barrel length and configuration options — from ultra-compact CQB to full-length designated marksman configurations.
-
01B2B COMMERCIAL / EXPORT
VM4 Series
The VM4 Series is a heavy-duty, high-visibility vehicle mirror system engineered to deliver maximum field of view and operational durability in demanding environments. Featuring a compact 200 x 200 mm (7.8" x 7.8") high-clarity lens, it enhances operator situational awareness, reduces blind spots, and withstands harsh vehicular vibration and environmental conditions.
-
02B2B COMMERCIAL / EXPORT
MA-640
The MA-640 is an extended S-curve vertical mirror mounting arm engineered for medium-duty commercial and fleet vehicles requiring a right-hand offset along with high overhead clearance. Precision-fabricated with a 16 mm tubular profile featuring a swan-neck S-bend attached to a heavy-duty single-pivot hinge base, it ensures optimal field-of-view positioning, low wind resistance, and superior vibration dampening under rugged operational conditions.
-
03B2B COMMERCIAL / EXPORT
KVA-005
The KVA-005 is a wide-reach angled extension mirror mounting arm designed for medium-duty commercial and utility vehicles requiring extended lateral clearance and downward viewing angles. Constructed with a broad square mounting plate and a continuous tubular boom featuring a downward elbow bend, it delivers maximum stability, high torsional strength, and effective vibration mitigation under rugged operating conditions.
-
04B2B COMMERCIAL / EXPORT
KVA-004
The KVA-004 is a rigid, angled extension mirror mounting arm engineered for medium-duty commercial and utility vehicles requiring fixed outward reach and downward angle positioning. Built with a solid flat baseplate mount connected to a tubular boom featuring a distinct downward bend, it ensures optimal field-of-view extension, high structural rigidity, and effective vibration dampening under rugged operational conditions.
-
05B2B COMMERCIAL / EXPORT
MA22-079-01-4-T6
The MA22-079-01-4-T6 is a full-frame, dual-anchor closed loop mounting assembly engineered for heavy-duty vehicle mirror systems requiring maximum structural rigidity and stability. Precision-machined from high-strength T6-grade aluminum alloy, it features a C-clamp dual-hinge configuration with top and bottom mounting blocks connected by a multi-bay vertical frame, providing exceptional torsional strength, wind-load resistance, and vibration isolation under severe operational environments.
-
06B2B COMMERCIAL / EXPORT
VM1R Series
The VM1R Series is a robust vehicle mirror designed to provide a wide and clear rearward view for demanding vehicle applications. Its large 305 × 205 mm lens offers enhanced visibility, making it suitable for commercial, utility, tactical, and heavy duty vehicles.
-
07B2B COMMERCIAL / EXPORT
MA-615
The MA-615 is an extended horizontal-outreach mirror mounting arm engineered for medium-duty commercial and utility vehicles requiring wide lateral extension and optimal field of view. Designed with a continuous tubular boom featuring a sweeping 90-degree bend mounted to a heavy-duty single-pivot hinge base, it delivers superior structural stability, low wind drag, and exceptional vibration dampening under severe field conditions.
-
08B2B COMMERCIAL / EXPORT
MA-635
The MA-635 is an S-curve extended vertical mirror mounting arm engineered for medium-duty commercial and fleet vehicles requiring lateral offset along with high overhead clearance. Designed with a continuous tubular boom featuring an offset swan-neck bend attached to a heavy-duty single-pivot hinge base, it ensures optimal field-of-view positioning, aerodynamic stability, and vibration dampening under rugged operational conditions.
