Throw
311mm -
Height
603mm -
Diameter
Ø 22mm -
Material
Aluminium
MA22-098-01-4-T6
The MA22-098-01-4-T6 is an extended-outreach mounting arm assembly designed for wide-body vehicles requiring significant side clearance and overhead riser positioning. Precision-crafted from high-strength T6-grade aluminum alloy, it features a widened dual-window horizontal extension paired with an ultra-tall vertical stem, delivering optimal structural load balance, drag stability, and vibration dampening under rugged operational conditions.
ENQUIRE NOW-
B2B COMMERCIAL / EXPORT
Full System Specifications
Structural & Material Specifications
-
Material Grade
6061-T6 Aircraft-Grade Aluminum Alloy
-
Surface Treatment
Anti-Corrosion Thermal Powder Coat
-
Frame Profile
Extended Dual-Bay Horizontal Truss with Extra-Long Vertical Riser
-
Structural Rating
Extended-Reach Industrial
Mounting & Environmental Performance
-
Base Mounting Interface
Heavy-Duty Single-Hinge Pivot Block with Integrated Retention Hardware
-
Load Capacity
Up to 21 kg (46.3 lbs) Static / 12.5 kg (27.5 lbs) Dynamic
-
Vibration Dampening
Internal High-Density Polyurethane Isolation Bushings
-
Environmental Resistance
Full Salt-Spray, UV Degredation, and Severe Weather Protection
Available Variants
Multiple barrel length and configuration options — from ultra-compact CQB to full-length designated marksman configurations.
-
01B2B COMMERCIAL / EXPORT
KVA-005
The KVA-005 is a wide-reach angled extension mirror mounting arm designed for medium-duty commercial and utility vehicles requiring extended lateral clearance and downward viewing angles. Constructed with a broad square mounting plate and a continuous tubular boom featuring a downward elbow bend, it delivers maximum stability, high torsional strength, and effective vibration mitigation under rugged operating conditions.
-
02B2B COMMERCIAL / EXPORT
MA-526
The MA-526 is an extended angled mirror mounting arm designed for medium-duty commercial and utility vehicles requiring high lateral outreach and overhead positioning. Precision-engineered with a heavy-duty single-pivot hinge base and a continuous tubular boom extended at an upward angle, it offers an expanded field of view, drag resistance, and reliable vibration dampening in tough operational environments.
-
03B2B COMMERCIAL / EXPORT
MA22-079-01-4-T6
The MA22-079-01-4-T6 is a full-frame, dual-anchor closed loop mounting assembly engineered for heavy-duty vehicle mirror systems requiring maximum structural rigidity and stability. Precision-machined from high-strength T6-grade aluminum alloy, it features a C-clamp dual-hinge configuration with top and bottom mounting blocks connected by a multi-bay vertical frame, providing exceptional torsional strength, wind-load resistance, and vibration isolation under severe operational environments.
-
04B2B COMMERCIAL / EXPORT
MA-635
The MA-635 is an S-curve extended vertical mirror mounting arm engineered for medium-duty commercial and fleet vehicles requiring lateral offset along with high overhead clearance. Designed with a continuous tubular boom featuring an offset swan-neck bend attached to a heavy-duty single-pivot hinge base, it ensures optimal field-of-view positioning, aerodynamic stability, and vibration dampening under rugged operational conditions.
-
05B2B COMMERCIAL / EXPORT
MA22-065-01-4-T6
The MA22-065-01-4-T6 is an ultra-tall, compact-base mounting arm assembly engineered for heavy-duty vehicular mirror applications requiring maximum vertical clearance with minimal lateral footprint. Crafted from high-strength T6-grade aluminum alloy, it combines a streamlined single-window base frame with an extra-long upright riser stem, offering exceptional structural rigidity, wind-load resistance, and vibration dampening under severe field conditions.
-
06B2B COMMERCIAL / EXPORT
MA22-057-01-4-T6
The MA22-057-01-4-T6 is an extended-vertical mounting arm engineered for specialized vehicle mirror setups requiring high overhead clearance paired with a compact footprint. Precision-machined from high-strength T6-grade aluminum alloy, it features a single-window square base loop coupled with an extra-long vertical riser stem to provide stable positioning and vibration dampening under severe field conditions.
-
07B2B COMMERCIAL / EXPORT
MA22-039-01-4-T6
The MA22-039-01-4-T6 is a compact, high-rigidity mirror mounting arm engineered for tight-clearance vehicular applications requiring high stability. Built with a single-bay reinforced loop body and an ultra-tall vertical upright, this high-strength T6 aluminum alloy arm offers maximum structural support and vibration reduction while maintaining a slim lateral profile.
-
08B2B COMMERCIAL / EXPORT
VM5 Series
The VM5 Series is a premium, extended-view vehicle mirror system engineered for maximum blind-spot reduction and operational safety in high-risk environments. Featuring an expanded 196 x 296 mm (7.71" x 11.65") high-clarity lens, it delivers ultra-wide coverage, superior rearward visibility, and robust vibration damping across heavy industrial and military fleet applications.
