Throw
130mm at 10° -
Height
80mm at 38° -
Diameter
Ø 16mm -
Material
Mild Steel
KVA-005
The KVA-005 is a wide-reach angled extension mirror mounting arm designed for medium-duty commercial and utility vehicles requiring extended lateral clearance and downward viewing angles. Constructed with a broad square mounting plate and a continuous tubular boom featuring a downward elbow bend, it delivers maximum stability, high torsional strength, and effective vibration mitigation under rugged operating conditions.
ENQUIRE NOW-
B2B COMMERCIAL / EXPORT
Full System Specifications
Structural & Material Specifications
-
Material Grade
Mild Steel
-
Frame Profile
Broad Square Baseplate Mount with Extended Angled Boom
-
Surface Treatment
Premium Matte Black Powder Coating
-
Structural Rating
Medium-Duty Commercial Standard
Mounting & Environmental Performance
-
Base Mounting Interface
Heavy-Duty Broad Square Baseplate Mount
-
Compatible Clamp Size
Multi-fit 10 mm to 46 mm clamp assemblies
-
Vibration Dampening
Integrated High-Durometer Isolation Bushings / Gaskets
-
Environmental Resistance
Weatherproof, UV-Stabilized, and Salt-Spray Protected
Available Variants
Multiple barrel length and configuration options — from ultra-compact CQB to full-length designated marksman configurations.
-
01B2B COMMERCIAL / EXPORT
MA22-090-01-4-T6
The MA22-090-01-4-T6 is an extra-tall, heavy-duty closed-loop mounting assembly engineered for large-scale commercial and tactical vehicle mirror systems requiring maximum vertical span and structural integrity. Precision-crafted from high-strength T6-grade aluminum alloy, it features dual-anchor hinge blocks linked by a reinforced, double-window vertical frame, offering unmatched resistance against severe vibration, mechanical stress, and high-speed wind resistance.
-
02B2B COMMERCIAL / EXPORT
MA-635
The MA-635 is an S-curve extended vertical mirror mounting arm engineered for medium-duty commercial and fleet vehicles requiring lateral offset along with high overhead clearance. Designed with a continuous tubular boom featuring an offset swan-neck bend attached to a heavy-duty single-pivot hinge base, it ensures optimal field-of-view positioning, aerodynamic stability, and vibration dampening under rugged operational conditions.
-
03B2B COMMERCIAL / EXPORT
VM4 Series
The VM4 Series is a heavy-duty, high-visibility vehicle mirror system engineered to deliver maximum field of view and operational durability in demanding environments. Featuring a compact 200 x 200 mm (7.8" x 7.8") high-clarity lens, it enhances operator situational awareness, reduces blind spots, and withstands harsh vehicular vibration and environmental conditions.
-
04B2B COMMERCIAL / EXPORT
VM3 Series
The VM3 Series is a heavy-duty, high-visibility vehicle mirror system engineered to deliver maximum field of view and operational durability in demanding environments. Featuring a compact 207 x 146 mm (8.1" x 5.74") high-clarity lens, it enhances operator situational awareness, reduces blind spots, and withstands harsh vehicular vibration and environmental conditions.
-
05B2B COMMERCIAL / EXPORT
MA22-057-01-4-T6
The MA22-057-01-4-T6 is an extended-vertical mounting arm engineered for specialized vehicle mirror setups requiring high overhead clearance paired with a compact footprint. Precision-machined from high-strength T6-grade aluminum alloy, it features a single-window square base loop coupled with an extra-long vertical riser stem to provide stable positioning and vibration dampening under severe field conditions.
-
06B2B COMMERCIAL / EXPORT
MA22-080-01-4-T6
The MA22-080-01-4-T6 is an extended dual-bay closed-loop mounting assembly engineered for heavy-duty vehicular mirror systems requiring maximum stability and extended outward reach. Precision-machined from high-strength T6-grade aluminum alloy, it features dual-anchor hinge mounting blocks connected by a multi-window reinforced frame, providing exceptional torsional rigidity, wind-load resistance, and vibration isolation under severe operational conditions.
-
07B2B COMMERCIAL / EXPORT
MA22-051-01-4-T6
The MA22-051-01-4-T6 is an ultra-tall, gusset-reinforced heavy-duty mounting arm designed for severe-duty vehicle applications demanding high structural stability at maximum vertical reach. Crafted from high-strength T6-grade aluminum alloy, it features an integrated diagonal truss strut bridging the dual-bay base frame to an extra-long vertical riser, providing exceptional rigidity against high-speed wind loads and heavy dynamic vibration.
-
08B2B COMMERCIAL / EXPORT
MA22-062-01-4-T6
The MA22-062-01-4-T6 is an extended dual-bay mounting arm assembly engineered to provide exceptional outboard reach and vertical clearance for commercial and tactical vehicle mirror systems. Precision-fabricated from high-grade T6 aluminum alloy, it features a widened dual-window horizontal extension paired with an extra-tall upright riser to ensure solid structural support, drag resistance, and vibration isolation under high-speed operational conditions.
